Specification

Conforms to ISO 6507 / ASTM E92 / JIS Z 2244
Test loads
Vickers: HV 0.05, 1, 0.2, 0.25, 0.3, 0.5, 1, 2, 2.5, 3, 4, 5, 10, 20, 30, 50 kgf
Knoop: HK 0.05, 1, 0.2, 0.3, 0.5, 1, 2 kgf
Brinell: HBW 1/1, 1/2.5, 1/5, 1/10, 1/30, 5/6.25, 2.5/15.6, 2.5/31.25 mm/kgf
Optimal load setting: Possible to set max 64 kinds of test load in a range of 05-50Kgf by min 0.01Kgf
Loading system - 0.05-50Kgf Test Load: Automatic direct loading system with load-cell closed-loop feedback
Load-Cell Type - 0.05-50Kgf: by double load-cell (apply test load by 10gf)
Load Applying Speed
Initial Descending Speed (to 0.15mm level on specimen surface): Approx. 180um/s
Effective Loading Speed: Approx. 30um/s for under 1kgf Test Load and Approx. 80um/s for over 1kgf Test Load
Dwell Time - 5-99sec
Indenter
For Vickers Test (HV): 1pc
For Knoop Test (HK) and Brinell Test (HBW): Tungsten Ball 1mm, dia. 2.5mm (OPTION)
Objective Lens
Infinity Corrected Long Working Distance (LWD) Lens 2pcs: X10 & X50
Infinity Corrected LWD Lenses / Max. 5pcs: X1.25, X2.5, X5, X20, X40, X100 (OPTION)
System control
Software - FT-ZERO (Windows 10 / 64bit) / Display Size 23"
Output Signal - USB (RS232C Converter: built-in)
Dimensions - Auto 150 x 150 mm
X-Y Stage Movement - AUTO MAX MOVEMENT : (X)180 x (Y)110mm with joystick controller
Max height of specimen - 210mm From Auto Stage Top
Max depth of specimen - 180mm
Light Source
Bulb - LED illumination
Filter - Manual Adapting/Removing
Aperture Diaphragm - Flexible Type Aperture (OPTION)
Power Supply - 240v
Dimensions - 820x415x650mm
Weight - 95Kg
