The PreciCut 5000 precision cutting machine offers full control of cutting parameters with settings for automatic Y feed speed, wheel speed, coolant control and length of the cut. The system even has a intelligent cut mode with monitors the cutting process and adjusts the parameters to ensure a high quality cut is maintained. With a rotation speed from 100 RPM to 4000 RPM the PreciCut 5000 is suitable to cut almost any material. With easy maintenance and external re-circulation tank, high quality cutter is ensured.

    • Control panel displays all parameters and is used for selection and editing of programs.
    • With an external recirculation tank and coolant bars positioned at the cutting wheel, very high quality cutting is maintained on the most difficult samples.
    • The cutting arm is used for the sectioning of difficult samples and offers X movement to allow slicing of samples to accurate measurements.
    • Various vice options are available to accept difficult samples.
    • Special machine control mode gives resistance monitoring and speed of cut control.
    • Emergency stop to completely close down the machine in the event of an incident.
  • T Slot Table180 x 118 ( L x D) 10 mm T slot
    X axis40 mm by Manual
    Y axis200 mm
    Z axis ( Verticle)Fixed - it is not possible to move up & down
    Feed speed mm per minute min0.001mm second /6mm per min
    Feed speed mm per minute max5 mm second /150mm per / min
    For automaticY movement only ( Table Forward / Reverse)
    Automatic Y axis (serial cuts)Not possible
    Opening on left side and right sideTop open door system
    Maximum wheel size8" ( 200 mm)
    Maximum cutting capacity40 mm
    Variable speed range100 to 3000 rpm
    Motor0.75 Kw (1 Hp)
    Laser PositioningOptional
    Recirculating System20L capacity
    Arbour Size12.7 mm / 25mm ( with flange )
    Electronic control5.7" PLC with HMI
    Electronic travel measuringY Movement
    Cutting Force dependent speed control              Yes available
    Automatic Pulse cuttingYes available
    Step cut/ Diagonal cut.Step cutting / continuous cutting
    Direct Positioning Via JoystickSpecimen positioning via joystick
    Current safety StandardsDoor limit switch and interlock
    LED illuminationYes available
    Power Supply230 V/ 50 Hz ( Single Phase)
    Size600x680x460mm (door closed) / 600x680x850mm (door open)
    Machine Weight105kg
